GFMH Series

Home

Products

Energy Storage Battery

GFMH Series

High temperature battery

High temperature battery

Product features:

● GFMH series battery has a wide temperature range and outstanding high temperature performance. It can be used in the range of -25℃~+75℃. The battery can be used in the range of 15~40℃ for a long time.
● Corrosion resistant grid, and in the negative plate to add special high temperature additives, greatly increase the life of the battery, 35℃ temperature, design float charge life up to 10 years.
● Radiation grid structure, battery charging capacity is stronger, high current discharge capacity is excellent.
● ABS engineering plastic shell, high and low temperature resistance, corrosion resistance, strong earthquake resistance, not easy to deformation.
● The use of improved ultrafine glass fiber separator, excellent resilience, low internal resistance, high porosity, gas recombination rate of 99%.
● Using CW-M-109 sealant, viscosity is very strong, aging resistance, corrosion resistance and high toughness.
● Safety valve for improved plastic cap, high accuracy of exhaust pressure, limited to prevent battery bulge or water loss.

Certificate

Product advantage:

● The shell is made of PC+ABS synthetic resin, with the highest temperature resistance of 105℃;

● Grid adopts high tin low calcium alloy grid to increase corrosion resistance;
● And paste using low density sulfuric acid, and add 4BS seeds, increase battery life;
● The separator adopts high temperature separator to prevent the aperture from changing at high temperature;

● Increase the battery electrolyte storage, supplement the high temperature battery during the use of water loss.

Application areas:
● High temperature environment, base station in perennial high temperature environment,

● Areas with average temperature of 30 ℃ and above,

● Base station in remote unmanned area;

● Solar and wind energy storage system.

Model	Nominal Voltage(V)	Capacity(Ah)	Weight(kg)	Length(mm)	Width(mm)	Height(mm)	Terminal
GFMH100-12	12	100	31	395	110	286	M6
GFMH150-12	12	150	48	550	111	314	M6
GFMH200-12	12	200	58	560	125	317	M8
